Penlink > Products > Rotary Unions > Standard Rotary Unions > 100 Series Swivel
100 Series Swivel

100 Series Swivel

Lightweight and Efficient Fluid Transfer Solutions

The 100 Series Rotary Unions are engineered to provide efficient and reliable performance in demanding industrial applications. Designed to handle pneumatic, vacuum, and hydraulic mediums, this series is the ideal choice for industries requiring precision fluid transfer with a focus on durability and efficiency.

Categories: Standard Rotary Unions, Rotary Unions
  • Description
  • Specifications

100 Series Swivel

Compact Design, High Performance

The 100 Series features a self-supported, single-flow joint with a radial housing connection as standard, making it a versatile option for various applications. Its lightweight aluminum housing and steel shaft ensure durability while maintaining low torque for smooth operation. Straight models and stainless steel shafts are available upon request, providing flexibility to meet unique operational requirements.

With its low torque and lightweight design, the 100 Series stands out for its ease of use and adaptability. Whether you’re working with pneumatic systems, vacuum setups, or hydraulic operations, this rotary union offers dependable performance. For specialized applications, consult the factory to explore tailored solutions that align perfectly with your operational needs.

Mediums

  • Pneumatic
  • Vacuum
  • Hydraulics
Maximum Pressure

Air 10 bar (150 psi), Vacuum 7 kPA (2″ Hg), Hydraulic 70 bar (1,050 psi)

Maximum Speed

3,500 RPM  (3,500 minˉ¹)

Max. Temperature

120ºC (250ºF)

*Max. hydraulic pressure decreases with increasing speed. Do not work with max. pressure at max. speed.

100 Series Swivel

Technical Specification
# B A Thread Type D E F G L1 L U V Z Weight kg (lbs)
1 DN06 G 1/8″ G 1/8″
M10 x 1
PLOT M10 x1
32
32
32
11
11
11
18
18
21
6
6
6
46
46
44.5
66.5
66.5
69.5
–
–
11 h6
–
–
3
15
15
15
0.155 (0.31)
0.155 (0.31)
0.135 (0.31)
2 DN08 G 1/4″ G 1/4″ 37 13.5 21.5 8 47.5 70.5 – – 17 0.185 (0.38)
3 DN10 G 3/8″ G 3/8″
M16 x 2
39
39
14.5
14.5
24
24
10
10
56.5
56.5
83.5
83.5
–
–
–
–
22
22
0.310 (0.633)
0.310 (0.633)
4 DN15 G 1/2″ G 1/2″
PLOT M20 x 1.5
PLOT M27 x 1.5
M35 x 1.5
G 3/4″
52.5
52.5
52.5
58
58
18
18
18
20
20
29.5
34.5
35.5
33
33
15
15
15
15
15
70.5
69
69
78.5
78.5
105
110
111
119
119
–
22 g6
28 g6
–
–
–
5
6
–
–
28
28
32
40
36
0.64 (1.31)
0.64 (1.31)
0.64 (1.31)
0.795 (1.622)
0.795 (1.622)
5 DN20 G 3/4″ G 3/4″
PLOT M27 x 1.5
M35 x 1.5
58
58
58
20
20
20
33
39
33
20
20
20
78.5
77
77
119
125
119
–
28 g6
–
–
6
–
36
36
40
0.795 (1.622)
0.795 (1.622)
0.795 (1.622)
6 DN25 G 1″ G 1″
PLOT M35 x 1.5
68
68
21
21
36.5
48.5
25
25
84.5
84.5
126
138
–
40 g6
–
12
40
45
1.03 (2.1)
1.03 (2.1)
7 DN32 G 1 1/4″ G 1 1/4″ 82 23 43 32 106.5 159 – – 50 1.75 (3.57)
8 DN40 G 1 1/2″ G 1 1/2″
M50 x 1.5
96
96
23
23
48
48
40
40
122
122
180
180
–
–
–
–
60
60
3 (6.12)
3 (6.12)
