Penlink > Products > Fiber Optical Rotary Joints > Multi Channel > JXn-Serie
JXn-Serie

JXn-Serie

Rugged & Reliable Multi-channel Fiber Rotary Joint

Evolved from the successful MJn model, JXn series FORJs has become the most popular multi-channel FORJs. Maximum channel count is 19 (2-7, 8-12, or 13-19). Like all our FORJs, they are “blind-spot free” and are designed for harsh environments.

Categories: Fiber Optical Rotary Joints, Multi Channel
  • Description
  • Specifications

JXn-FORJ Series

Multi Channel Fiber Optical Rotary Joint

JXn series multi-pass Fibre Optic Rotary Joints (FORJs) can accommodate 2-7, 8-12, or 13-19 independent fibre channels as standard options. When the channel count is eight or higher, the stator body length is slightly longer. Loss and back reflection is uniform across all channels. There is no channel “drop off” or “blind spot” during rotation. They feature low crosstalk performance (<-60 dB) for both single and multi-mode fibres.

This model shares the same body diameter and mounting schemes with MJn series FORJs. However, the JXn design makes it more convenient to integrate with electrical slip rings. Pressure compensation is available as an option. Like our other multi-channel FORJs, all channels can accommodate either singlemode or multimode fibres. It is also possible to combine the two types of fibres in one device across three optical windows (850, 1310, and 1550 nm).

Note: All insertion loss and return loss measurements are performed by joining the FORJ to the light source through a fusion splice (without the use of connectors). Insertion loss of all receptacle types of FORJs, such as RST, RFC, and RFCX, are measured with connectors of similar type. Their return loss is not measured.

Quick Specifications
Parameters Values
Wavelength 1270-1610 nm for SM; 850 and 1310 nm for MM
Maximum Speed 200 rpm
Housing Material Stainless Steel
Fiber Types SM or MM w/3 mm jacket, 1 m (Kevlar/PVC or armor)
Vibration MIL-STD-167-1A
IP Rating Up to IP 65
Relevant Documents

Which fiber should I choose: Explaining Fiber, Simplex, Duplex, Multiplexer and more!

JXn-FORJ Series

Technical Specification



Parameters Values
Wavelength 1270-1610 nm for SM; 850 and 1310 nm for MM
Insertion loss <5 dB (typical: 2-3 dB)
Insertion loss ripple ~+/-0.5 to 1 dB
Return loss (SM) 45 dB
Crosstalk >50 dB (typical: 63 dB)
Chromatic dispersion <0.01 ps/nm
Polarization mode dispersion <0.01 ps
Maximum speed 200 rpm
Pulling strength 10 N
Start up torque <1 Nm
Estimated life cycle 100 million revolutions
Optical power handling 23 dBm
Working temperature -20 to 65°C
Storage temperature -25 to 75°C
Package style Pigtails or receptacles (FC or ST; up to 7 channels)
Housing material Stainless steel
Fibre types SM or MM w/3 mm jacket, 1 m (Kevlar/PVC or armor)
Connector types FC, SC, ST, SMA, LC or /APCs
Dimensions 67 mm dia. x 122 mm length
Weight 2.5 kg
Vibration MIL-STD-167-1
Mechanical shock MIL-STD-810F
IP rating Up to IP 65
